Product Catalog - Ash Handling Components

Ash Conveying Wear Parts

• 4″ Ash Venturi Throat CastingsTF1160Venturi Throat Casting for 4" Sched. 40 pipe - TF Hi-Chrome @ 650+ BHn

• 12″ Rotor/Seal Assembly CastingsTF225/TF22612" Joy Style Rotor/Seal Castings

• 12″ Rotary Valve/Seal AssemblyTF648/TF64912" DSC Style Rotor/Shoe Assembly - Machined TFD100

• 6″ Ash Venturi Throat CastingTF8956" Ash Re-Injection Venturi Throat Casting - Machined TF Hi-Chrome @ 650+ BHn

• Ashtek Style Paddles – 8.5″TF179Ash Conveyor Wear Paddle - TF Hi-Chrome @ 650+ BHn

• Ash Conveyor Split SprocketsTF23510 tooth split sprockets - 4140 Q&T -

• Ashtek Style Paddles – 6″TF174Ash Conveyor Wear Paddle - TF Hi-Chrome @ 650+ BHn

Cones & Vanes

• 6″ Ash Collector Tube w/integral VaneTF105Cone assembly w/2 piece bolt on tip; TFNH1 @ 550+ BHn

• 9″ cyclone inlet tubeTF106 & TF106BReplacement Zurn Style 9" Cyclone Inlet Tube w/removable boot - TF NH1

• 12″ Ash Multiclone Swirler/VaneTF102V8 vane swirler/vane casting for TF102 12" cone - TFDI100

• 9″ MultiClone – Ash Collector ConeTF103Replacement Type VGR 9" Multi-Cone, TFNH1 @ 550+ BHn

• 10″ ASH MULTICLONE – SWIRLER/VANETF108V10" Cone - Swirler/Vane - 11 blades - TFDuctile100

• 9″ Ash Multiclone – swirler/vaneTF103V9" Cone - Swirler/Vane - TFDuctile100 or NH1
